Description
| Part Number |
Size inch |
WLL 6:1 ton |
A mm |
B mm |
C mm |
D mm |
E mm |
F mm |
G mm |
H mm |
Weight kg/100 |
Sacks of pcs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SHGPB08SA | 1/4″ | 0.5 | 7 | 8 | 12 | 28 | 20 | 41 | 16 | 44 | 5.5 | 25 |
| SHGPB10SA | 5/16″ | 0.75 | 8 | 10 | 13 | 31 | 21 | 50 | 20 | 52 | 10 | 25 |
| SHGPB11SA | 3/8″ | 1.0 | 10 | 11 | 16 | 36 | 26 | 57 | 22 | 60 | 17 | 25 |
| SHGPB13SA | 7/16″ | 1.5 | 11 | 13 | 18 | 43 | 29 | 67 | 25 | 70 | 24 | 25 |
| SHGPB16SA | 1/2″ | 2.0 | 13 | 16 | 22 | 51 | 32 | 80 | 32 | 84 | 34 | 25 |
| SHGPB19SA | 5/8″ | 3.25 | 16 | 19 | 26 | 64 | 43 | 95 | 38 | 104 | 63 | 20 |
| SHGPB22SA | 3/4″ | 4.75 | 19 | 22 | 31 | 76 | 51 | 112 | 44 | 123 | 95 | 10 |
| SHGPB25SA | 7/8″ | 6.5 | 22 | 25 | 36 | 83 | 58 | 127 | 50 | 136 | 155 | 5 |
| SHGPB28SA | 1″ | 8.5 | 25 | 28 | 43 | 95 | 68 | 147 | 56 | 153 | 230 | 5 |
| SHGPB32SA | 1 1/8″ | 9.5 | 28 | 32 | 47 | 108 | 75 | 165 | 64 | 176 | 324 | 4 |
| SHGPB35SA | 1 1/4″ | 12.0 | 32 | 35 | 51 | 115 | 83 | 178 | 70 | 190 | 440 | 3 |
| SHGPB38SA | 1 3/8″ | 13.5 | 35 | 38 | 57 | 133 | 92 | 194 | 76 | 216 | 600 | 1 |
| SHGPB42SA | 1 1/2″ | 17.0 | 38 | 42 | 60 | 146 | 99 | 202 | 84 | 236 | 750 | 1 |
| SHGPB50SA | 1 3/4″ | 25.0 | 45 | 50 | 74 | 178 | 126 | 243 | 100 | 286 | 1400 | 1 |
| SHGPB57SA | 2″ | 35.0 | 50 | 57 | 83 | 197 | 146 | 269 | 115 | 320 | 1829 | 1 |
| SHGPB65SA | 2 1/4″ | 42.5 | 57 | 65 | 95 | 222 | 160 | 303 | 130 | 350 | 2606 | 1 |
| SHGPB70SA | 2 1/2″ | 55.0 | 65 | 70 | 105 | 254 | 185 | 329 | 140 | 407 | 4200 | 1 |
| SHGPB83SA | 3″ | 85.0 | 75 | 83 | 127 | 330 | 190 | 373 | 180 | 505 | 6900 | 1 |
