Sizes: 10mm - 13mm
This short link chain is extra strong, low stretch and high breaking load. High quality raw materials. Not appropriate for lifting.
| Part Number |
Diameter mm |
Inside Length (Pitch) mm |
Inside Width mm |
Outside Width mm |
Outside Length mm |
Safe Working Load 5:1 ton |
Minimum Breaking Load ton |
Weight kg/m |
|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | ||||
| CHG110S | 10.0 | 30.0 | 13.5 | 33.5 | 50.0 | 4.00 | 20.00 | 2.17 |
| CHG113S | 13.0 | 39.0 | 18.0 | 44.0 | 65.0 | 6.70 | 33.50 | 3.67 |
